    Compact NFC RFID Reader Desktop Square NFC Card Reader Integrated Key Handling

    Ask Lasest Price
    Brand Name : Andea Electronics
    Model Number : RL863
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 500~1000 PCS Per Month
    Delivery Time : 3~5 work days
    • Product Details
    • Company Profile

    Compact NFC RFID Reader Desktop Square NFC Card Reader Integrated Key Handling

    Desktop NFC RFID Reader Multiple Protocols Reader USB Power Supply

    Product Introduction:

    The NFC desktop reader is ideal for cashless payment systems or loyalty schemes as well as to encode transponders for time & attendance. The intelligent reader firmware allows an easy and fast access to 13.56 MHz RFID chips without deep RFID knowledge and also supports NFC (Near field Communication)
    in active mode.

    It comes in an attractive glossy white housing with a bi-color LED and a buzzer which are completely controlled by the application via dedicated protocol commands. The simple commands of the intelligent RFID reader module facilitate a fast application development and a short time-to-market period.



    Main Features:

    • Super easy NFC / RFID chip handling
    • Intelligent NFC reader firmware by "embedded DLL"
    • Integrated key handling
    • Fast application development and time to market
    • LED brightness on image enhand to highlight their position​

    Technical Specification
    ModelRL863
    Operating Frequency

    13.56 MHz (±7KHz)

    Compatible Protocols

    ISO15693, ISO 14443A/B, ISO 18000-3M3 and NFC

    Compatible Tags

    • NFC Forum Type 1: Innovision Topaz512

    • NFC Forum Type 2: Mifare Ultralight, Mifare Ultralight C, Mifare Ultralight EV1, NTAG21x.

    • NFC Forum Type 3: Sony Felica [only support Polling]

    • NFC Forum Type 4: Mifare DESFire EV1

    • NFC Forum Type 5: ICODE SLI ,ICODE SLIX ,ICODE SLIX2 ,Tag-it HF- I plus

    • Mifare Classic Type: Mifare S50, Mifare S70 ,Mifare Mini

    • ISO18000-3M3 Type: ICODE ILT

    • ST ISO14443B Type: SRIX4K, SRI512, ST25TB512-AC

    Communication InterfaceUSB
    Reading RangeISO 1569316cm
    ISO 14443A10cm
    ISO 18000-3M3——
    Keyboard EmulationSupport
    Anti-collision AlgorithmSupport
    Working VoltageDC 5V (USB power supply)
    Max Power Consumption0.6W
    Dimension105*70*10mm
    Weight53g


    What are the differens between NFC and RFID?

    NFC is a sub-category of high frequency RFID. NFC differs from RFID in that NFC is designed to provide secure peer to peer communications between two devices. Another key difference is that an RFID reader can scan for multiple RFID tags simultaneously whereas an NFC reader can only communicate with one other device at a time. RFID readers and writers are not RFID tags, however any NFC device is able to function as both reader and tag.

    Typical Applications:

    • Identification systems
    • Card personalization
    • Production test and chip encoding
    • Access control
    • Pross or transaction control
    • Payment systems & loyalty schemes
