    1- 8W Power RFID Gate Antenna Tag UID Detection Supported , HF RFID Reader 13.56MHz

    Ask Lasest Price
    Brand Name : Andea Electronics
    Model Number : LSG405
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 500~1000 Sets Per Month
    Delivery Time : 3~5 work days
    • Product Details
    • Company Profile

    1- 8W Power RFID Gate Antenna Tag UID Detection Supported , HF RFID Reader 13.56MHz

    13.56MHz RFID Gate Antenna For Anti-Theft EAS And AFI Alarm Mode

    Product Introduction:


    Andea LSG405 is a high performance HF 3D Gate Antenna device. Designed upon fully self-intellectual property, it supports fast tag anti-collision operation with high identification rate, 2 line infrared motion sensor with intelligent personnel movement direction determination and counting, EAS/AFI security surveillan, multiple gate synchronization, RS232/485 and TCP/IP interface, remote configuration and management. It is an ideal choice for various HF RFID application systems such as Library Anti-theft, Open Access Control, Conference Attendance, Process Control and Logistics etc.


    Product Features:


    • Three-dimensional orientation detecting, tags can be detected in all directions.
    • Aisle width more than 90 cm(relative to tags quality and size).
    • Support multiple -channel paralleling usage.
    • Support EAS and AFI optional detection
    • Support EAS+AFI mixed detection
    • Support Tag UID detection
    • Support direction discrimination and statistic the number of people check-in/ check-out.
    • 8bits digital tube display, counting No. of people check-in/ check-out and device parameters can be displayed
    • Support relay output control
    • Upgrade-able firmware, support redevelopment and custom-made as requirement

    Technical Specification
    ModelLSG405
    Compatible ProtocolsISO15693
    Alarm ModeEAS, AFI and EAS+AFI
    Passive AlarmSupport
    EMI DetectionSupport
    Aisle Width90cm
    Power SupplyAC 100-240V 50-60Hz
    Max Power Consumption30W (Rated Power 20W)
    Housing MaterialAcrylic and Metal Plate

    Dimension

    (L*W*H)

    Whole: 1664*636*118mm

    Antenna: 1645*600*44mm

    Base: 636*118mm

    Weight23 kg/pc
    Working Temperature-20℃~60℃
    Storage Temperature-45℃~85℃
    Relative Humidity5%~80%


    Product Application:


    RFID library management, RFID archive management, etc.
